CPU: Intel Atom C3758 Series Processor: 8core, 25W
Socket: SOC
System Memory
Capacity: 4 x 288-pin DDR4 DIMM slots
Type: Dual Channel DDR4 memory technology
Storage
SATA Controller: 13 x SATA3 6.0 Gb/s: 5 x SATA3 ports (SATA_0, SATA_1, SATA_2, SATA_3 and SATA_12) and 8 x SATA ports from 2 mini SAS HD connectors (SATA_4_7 and SATA_8_11)
Additional Storage Controller: Marvell 9172 x2 for 4 port SATA3 6.0 Gb/s
Ethernet
Interface: Gigabit LAN 10/100/1000 Mb/s
Management
BMC Controller: ASPEED AST2500 : IPMI (Intelligent Platform Management Interface) 2.0 with ikvm and vMedia support
Graphics
Controller: ASPEED AST2500
VRAM: DDR4 64MB
Output: Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
Internal Connector
Auxiliary Panel Header: 1 (includes chassis intrusion, location button & LED, front LAN LED, and event log LED)
TPM Header: 1
IPMB Header: 1
Fan Header: 4 pins x4 (1CPU/2Front/1Rear)
ATX Power: 1 (24-pin)
DC IN: 1 (8-pin) 12v
USB 2.0 Header: 1 (support 1 USB port or 2 USB ports on header. The port number controlled by USB_ SEL1 and USB_SEL2 jumper)
